Jelly Candy Production Line
We Are Not Only Capable Of Selling Products, But Also Have The Ability To Undertake Full Turnkey Projects.
⚙️ Overview
The Jelly Candy Production Line is a fully automated system designed for the continuous production of high-quality jelly and gummy candies.
It integrates cooking, mixing, depositing, cooling, and demolding processes to ensure precise shape, texture, and flavor consistency.
✅ Ideal for producing fruit-flavored jelly, vitamin gummies, pectin-based candies, and functional supplements.
✅ Suitable for gelatin, pectin, carrageenan, or starch-based formulations.
🚀 Key Features & Benefits
🧠 1. Full Automatic Control
Centralized PLC + HMI system allows one-touch recipe management.
Synchronizes cooking, depositing, and cooling automatically.
Ensures precise temperature, flow, and dosing control for uniform candy quality.
🍯 2. High-Precision Cooking & Mixing
Steam or electrical jacketed cooker with automatic syrup concentration control.
Uniform heating ensures ideal sugar-to-water ratio and stable texture.
Equipped with inline flavor, color, and acid dosing system for accurate formulation.
🍬 3. Efficient Depositing & Molding
Servo-driven depositors ensure high-speed and accurate candy dosing.
Depositing accuracy within ±0.2 g.
Compatible with multiple molds: bear, ring, bottle, fruit shape, or custom designs.
Adjustable depositing speed (20–60 times/min) depending on mold size.
❄️ 4. Cooling & Demolding System
Advanced cooling tunnel with air circulation and temperature regulation.
Ensures perfect jelly texture and prevents stickiness.
Automatic mold lubrication and demolding reduce product waste and downtime.
🧼 5. Hygienic & Easy Maintenance
All contact parts made of SUS304/316L stainless steel and food-grade silicone.
CIP (Clean-in-Place) system for automatic cleaning.
Modular structure allows easy disassembly and quick maintenance.
🔩 Technical Specifications
| Model | Capacity (kg/h) | Depositing Speed (times/min) | Candy Weight (g) | Power (kW) | Heating Type | Dimensions (mm) |
|---|---|---|---|---|---|---|
| JCL-150 | 150 | 20–40 | 1–5 | 16 | Steam / Electric | 12,000×1,800×2,100 |
| JCL-300 | 300 | 30–50 | 2–6 | 22 | Steam / Electric | 15,000×2,000×2,300 |
| JCL-450 | 450 | 40–60 | 2–8 | 28 | Steam / Electric | 18,000×2,200×2,500 |
💡 Customizable for sugar-free, vitamin-fortified, or functional gummies.
🧩 Production Flow
1️⃣ Raw Material Preparation (sugar, glucose, gelatin, color, flavor)
2️⃣ Cooking & Mixing (controlled heating and homogenizing)
3️⃣ Dosing & Flavor Injection (automatic inline dosing)
4️⃣ Depositing into Molds (servo-driven precision system)
5️⃣ Cooling Tunnel (air-cooled or water-cooled)
6️⃣ Demolding & Drying
7️⃣ Sugar Coating / Oil Polishing (optional)
8️⃣ Packing & Weighing
🏭 Applications
| 🍓 Fruit Jelly | 🧃 Vitamin Gummy | 🌿 Functional Candy | 🧸 Shaped Gummies | 🍊 Pectin Candy |
|---|---|---|---|---|
| Mango, Strawberry, Orange | Vitamin C, D, Zinc | Herbal, Collagen, CBD | Bear, Bottle, Heart | Pectin or Carrageenan-based jellies |
🔧 Optional Equipment
| Function | Description |
|---|---|
| Automatic Ingredient Dosing | Precise liquid and powder dosing control for flavors and colors. |
| Oil Polishing Drum | Adds gloss and prevents stickiness on finished candies. |
| Sugar Coating Drum | For traditional sugar-coated jelly or chewy sweets. |
| Cooling Tunnel Extension | For high-humidity or tropical climate operation. |
| Packaging Machine Integration | Links directly to weighing and pillow-packing systems. |
💡 Advantages for Your Factory
✔ Consistent candy quality and texture in every batch
✔ Fully automatic, labor-saving operation
✔ Compatible with multiple candy formulas (gelatin, pectin, carrageenan)
✔ Quick mold changeover for various candy shapes
✔ Designed according to HACCP / CE / ISO9001 standards
🧠 Smart Control System
Recipe memory for up to 100 candy formulations.
Automatic temperature and pressure monitoring.
Real-time data logging for production traceability.
🧰 Operation & Maintenance
Modular design for easy part replacement.
Low maintenance cost with self-lubricating components.
Remote service support and online diagnostics available.
🧩 Complete Jelly Candy Line Configuration
Sugar Melting & Mixing System
Cooking & Vacuum System
Depositing Machine
Cooling Tunnel
Demolding Conveyor
Polishing / Coating Drum
Packing Line Integration
The system can be customized based on production capacity, recipe, and desired candy shape.
📞 Get a Customized Solution
Tell us your target capacity, candy type, and formula preference —
our engineers will design a tailor-made Jelly Candy Production Line layout optimized for your factory.
