Cucumber Canned Production Line

🥒As a leading food processing equipment manufacturer in China, we provide a fully automated Cucumber Canned Production Line designed for efficient, hygienic, and high-quality cucumber canning operations.
This complete line integrates washing, sorting, filling, sealing, sterilizing, and labeling processes — helping food factories and canning plants produce consistent, shelf-stable pickled cucumbers with minimum labor and maximum output.

🏭 Overview of the Cucumber Canning Solution

The Cucumber Canned Production Line is specially engineered for producing pickled and preserved cucumber cans or jars in different packaging formats.
Whether you’re producing tin-can pickled cucumbers, glass-jar gherkins, or PET-bottle pickles, the line can be customized according to your raw material characteristics and factory layout.

Our systems feature:

• Full stainless-steel structure (SUS304/316) for hygiene and corrosion resistance

• PLC automatic control system for easy operation

• Modular design for flexible assembly and easy maintenance

• Compatible with both metal cans and glass jars

• Adjustable production capacity: from 500 to 10,000 cans per hour

🔁 Cucumber Canning Process Flow

1. Raw Material Washing and Sorting
   High-pressure bubble washer removes mud, sand, and impurities. Vibrating screen and grading system ensure cucumbers are uniform in size.

2. Trimming and Cutting (Optional)
   Optional cutting system trims cucumber ends or slices them for specific product types.

3. Blanching and Cooling
   Thermal blanching helps retain color and crispness. Cooling section prevents overcooking.

4. Brining and Filling
   Automatic brine-filling machine adds cucumbers and brine precisely into each can or jar. The filling amount and salt concentration are adjustable.

5. Can Seaming or Jar Capping
   Vacuum seamer or automatic capping machine ensures perfect sealing, preventing air entry and leakage.

6. Sterilization (Retort)
   Continuous or batch-type sterilizers ensure microbial safety and long shelf life.

7. Cooling, Drying, and Labeling
   Rapid cooling system prevents texture damage. Drying and labeling systems prepare the final retail packaging.

⚙️ Main Equipment List

🚀 Technical Features & Advantages

• Automation & Control:
  Integrated PLC + touch screen control panel for precise monitoring and easy operation.

• Hygienic Construction:
  All contact surfaces are made of food-grade stainless steel, resistant to acid and salt from brine.

• Energy Efficient:
  Optimized steam and water utilization to minimize operational costs.

• Flexible Packaging:
  Supports metal cans (100g–1000g), glass jars (250ml–1L), or PET bottles.

• CIP Cleaning System:
  Built-in cleaning pipelines ensure sanitary operation and easy maintenance.

• Safety & Compliance:
  Meets international standards including HACCP, ISO22000, CE, and GMP.

🧠 Application Scenarios

• Pickled cucumber canning plants

• Gherkin pickling factories

• Ready-to-eat vegetable processors

• Central kitchens and OEM pickle brands

• Vegetable export packaging facilities

🧩 Customization Options

We offer full customization for:

• Production capacity (500–10,000 cans/hour)

• Packaging format (tin, glass, PET)

• Factory layout design

• Semi-automatic or fully automatic control

• Retort type (steam, water spray, rotary)

• Labeling and date printing systems

🔬 Quality Control & Food Safety

The line follows strict quality management procedures:

• HACCP-based hazard analysis to identify critical control points (CCPs)

• CIP cleaning before and after each production cycle

• Temperature & pressure data recording during sterilization

• Full traceability system for every production batch

All systems are designed for zero contamination risk, meeting EU and FDA food-grade standards.

💡 Why Choose Our Cucumber Canning Line

✅ Over 15 years of experience in vegetable canning equipment manufacturing
✅ One-stop solution provider — from raw material cleaning to packaging
✅ Exported to 30+ countries including Spain, Thailand, Egypt, and South Africa
✅ Turnkey project support: design, installation, training, and after-sales service
✅ Competitive pricing and spare parts availability for long-term operation

❓ Frequently Asked Questions (FAQ)

Q1: Can this production line handle both tin cans and glass jars?
Yes. The system can be configured for metal cans, glass jars, or PET jars. Changeover parts make switching between packaging formats quick and easy.

Q2: What is the required steam and water supply for operation?
The standard line requires 0.4–0.6 MPa steam pressure and 2–4 m³/h cooling water flow rate, depending on capacity.

Q3: Can I customize the filling volume and brine concentration?
Absolutely. Both parameters are adjustable via the PLC control panel according to your recipe.

Q4: How long does installation take?
Typically 25–45 days depending on production scale and factory layout. Our engineers provide on-site installation and training.

Q5: How do I clean the system after production?
The line is equipped with a CIP automatic cleaning system for internal pipelines and tanks, ensuring quick and hygienic cleaning.

Q6: What’s the warranty period?
We offer 12 months warranty after commissioning and lifelong technical support.

Q7: Do you provide spare parts and after-sales service?
Yes, we maintain a full range of spare parts and provide online or on-site maintenance support worldwide.

🌍 Export & Support Services

We provide turnkey project support including:

• Factory layout & process flow design

• Equipment installation and commissioning

• Operator training and maintenance guidance

• Long-term supply of spare parts

With decades of experience serving food processing factories worldwide, we help clients reduce cost, improve efficiency, and achieve global food safety compliance.
