YL-980 Digital Metal Detector
We Are Not Only Capable Of Selling Products, But Also Have The Ability To Undertake Full Turnkey Projects.
📌 Application Scope:
Suitable for a wide range of industries including food, pharmaceuticals, chemicals, rubber and plastics, aquatic products, toys, garments, footwear, leather, knitting, and printing.
Capable of detecting ferrous metals and non-magnetic metals (such as gold, silver, copper, aluminum, and stainless steel).
◎ Product Features:
Imported multi-frequency detection technology with phase tracking, product tracking, and automatic balance calibration functions.
Built with a high-performance single-chip FPGA hardware platform and premium imported electronic components for reliability and performance.
User-friendly interface with automatic learning function to quickly acquire product characteristics and complete auto-setup.
Excellent protection: Fully sealed design with low power consumption, meeting IP67 protection grade.
Technology sourced from the U.S., focused on developing and manufacturing high-end inspection equipment.
Delivers performance comparable to imported models at up to 50% lower cost.
📐 Technical Specifications:
| Item | Spec Options |
|---|---|
| Model | YL-980 Digital Metal Detector |
| Passage Width (mm) | 300 / 400 |
| Passage Height (mm) | 80 / 100 / 120 / 150 |
| Belt Width (mm) | 270 (for 300mm passage) / 370 (for 400mm passage) |
| Detection Sensitivity (Fe Φ mm) | 0.6 / 0.7 / 0.8 / 1.0 |
| Detection Sensitivity (Non-Fe Φ mm) | 0.8 / 1.0 / 1.2 |
| Detection Sensitivity (SUS304 Φ mm) | 1.0 / 1.2 / 1.5 |
| Conveyor Length (mm) | 1330 |
| Belt Height from Ground (mm) | 750 ± 50 (customizable) |
| Protection Grade | IP67 |
| Memory Capacity | Stores up to 100 product profiles |
| Belt Material | Food-grade PVC (PU or modular belt optional) |
| Display | LED LCD Display |
| Operation Input | Touch-button operation |
| Alarm Mode | Stop with buzzer alarm; optional rejector system available |
| Machine Material | Full SUS304 food-grade stainless steel; complies with HACCP, GMP, FDA, and CAS standards |
| Machine Weight | Approx. 200kg |
| Motor | High-power motor (Taiwan-made); supports conveyor load of 1–15kg |
| Power Supply | AC220V ±10%, 50–60Hz (optional: AC110V / AC380V) |
| Operating Environment | Temperature: -18°C to 50°C; Humidity: 30%–90% RH |
